Features:
- Capacity: 1000~2000kg, with lift height 1600-3500mm.
- Lift Up/down by battery & manual driving.
- High-powered hydraulic pump, fast and powerful.
- It is used heavily in diverse material handling application.
- These stackers are primarily used in warehouse and stores for the stacking purpose.
- It is used in a wide range of industries on a day to day basis.
Semi electric stacker
|
Specification | 1t,1.6m/2t,1.6m | 1t,2m/2t,2m | 1t,2.5m/2t,2.5m | 1t,3m/2t,3m | 1t,3.5m/2t,3.5m |
Min height | 85mm |
Max height of stacker when lifting the max height(mm) | 2000
| 2510
| 3010
| 3510
| 4010 |
Original height(mm) | 2000
| 1560 | 1810
| 2060 | 2260 |
The size of the fork(mm) | outer width 640/ inner width 340 |
Drive fork length(mm) | 1150
|
Overall length (mm) | 1860
|
Overall width (mm) | 780
|
Small wheels size(mm) | 74*70
|
Load center(mm) | 450
|
Charger | 24V,15HA |
Battery | 12V 105HA(6-QW-105) |
Power unit | 12V 1.6KW |
