Introduction:
1. Loading range:0-8ton.
2. Application:horizational or vertical lifting of steel plate and other products.
3 Material:low carbon alloy steel precision forging,the load is heavier.
4. One piece of clamp is used for the testing, and one piece is recommended for lifting operation,balance beam is needed for horizontal lifting.
5. The loaded object shall not touch anything when operating, over loading is prohibited.
6. Tested load is 2 times of working load.
LC type horizontal lifting point
|
WLL (T)
| A (MM) | B (MM)
| C (MM) | D (MM)
|
1
| 169.5
| 32
| 1-13 | 45.5
|
2
| 230
| 43.5
| 3-22
| 58
|
3
| 244.5
| 50
| 8-30
| 47.5
|
5
| 353 | 60
| 10-45
| 63 |
